Product Description

Co2 Laser Water Chiller CW5000BG with 220V, 60Hz

1. Features of Co2 Laser water chiller CW-5000AG:

1) Convenient for installation and operation

2) Integrated electronic control, large digital displays

3) Single temperature, single control

4) Low flow alarm

5) Over heat and over low temperature alarm

6)One-stop automatic intelligent temperature control: in different environment, user does not need to change setting due to it will automatically switch
to appropriate operating temperature.



2. Specification of Co2 Laser water chiller:

Model	CW-5000AG	CW-5000BG	CW-5000DG
Voltage	AC 1P 220V	AC 1P 220V	AC 1P 110V
Frequency	50Hz	60Hz	60Hz
Current	1.4~2.1A		3.5~5.6A
Compressor power	0.295 KW	0.38KW	0.305KW
	0.40HP	0.52HP	0.41HP
Refrigerating capacity	2361Btu/h	2999Btu/h	2866Btu/h
	0.692KW	0.879KW	0.84KW
	595Kcal/h	756Kcal/h	722Kcal/h
Refrigerant	R-134a
Refrigerant charge	300g	320g	280g
Precision	±0.3 temperature
Reducer	Capillary
Protection	Overcurrent protection for compressor, flow alarm, over temperature alarm
Pump power	0.03KW
Tank capacity	6L
Inlet and outlet	External Φ10mm brass connector
Max. lift	10 M
Max. flow	10 L/min
N.W	26 Kgs
G.W	31 Kgs
Dimension	55 X 28 X 43 cm (L x W x H)
Package dimension	72 X 44 X 62 cm (L x W x H)





Price Terms︰ CIF , FOB . EXW

Payment Terms︰ T/T , Western Union ,Moneygram

Packing︰ Standared Export Package

Lead Time︰ 7 days after payments received

Product Image
