Product Description

20w Desktop Fiber Laser Marking Machine Price For Metal, Plastic,Aluminum Engraving and Marking

Desktop Fiber Laser Marking Machine adopts the imported fiber laser generator, high speed Galvo system to enable stable laser output and high quality laser mode. This model Laser Marking Equipment boasts for its fast marking speed, good marking effect and high efficiency to meet the demand of mass production. Furthermore Fiber Laser Marker also enjoys the advantages of easy operation, low running cost, and long-term trouble -free working and free from maintenance. All these factors devotes to its capacity to satisfy industrial production.

1. Specification:

Laser Type	Fiber Lasers
Wavelength	1064nm
Laser Pulse Frequency	20-80Khz
Beam Quality	<1.4M2
Peak Laser Power	5W/10W/20W/30W
Marking Speed	<9000MM/S
Marking Depth	<=0.3MM
Repetition Precision	±0.01MM
Min. Line Width	0.02MM
Min. Character	0.2MM
Cooling Mode	Air Cooling
Graphic Formats Supported	PLT. DST. AI. DXF. BMP.JPG.CAD. CDR. DWG
Power Source	AC 110/220V±10%, 50/60Hz
Working Temperature	10-35 C
Working Humidity	<75%(No condensation)
Working Environment	Clean. free of dust
Gross Power	<1000W
Safety Protection Class	IP54
Laser Generator Safety Class	IV
Adjustable Height Direction(Upper surface)	550-1200MM
Adjustable Height Direction(Side)	400-1500MM
Front And Back Direction Adjustable Distance	0-200MM
Marking Angles	Any Angles

2. Feature:

One-unit structure with manually focusing system and user-friendly operation.
Imported isolator for protection of the fiber laser generator to increase the stability and prolong the laser life.
Laser beam quality is much better than the traditional laser marking machine. Fiber laser beam mode is TEM00; focus diameter is less than 20um; expanding angle is only 1/4 of the YAG-DP. Therefore it is esp. good at delicate marking.
High electricity-laser exchange ratio, gross electricity consumption is less than 500W, which is 1/10 of the YAG’s consumption
Free from maintenance, long working life, small size, suitable for any working environment
Fast marking speed, 2-3 times faster than the traditional marking machine
The marking software supports files such as CorelDraw, AutoCAD, Photoshop and PLT,PCX,DXF, BMP; SHX OR TTF can be directly adopted; the functions such as auto coding for sequence No., group mark, date, barcode and so on.

3. Applicable Materials:

Fiber Laser Marking Machine is suitable for all kind of metal, industrial plastic, electroplates, metal-coated materials, rubbers, ceramics and so on.

4. Applicable Industry:

This series Fiber Laser Marker widely used in mobile button, plastic transparent button, electronic parts, IC, tools, communication products, bathing products, tool accessories, glasses and watches, jewelry, button decoration for boxes and bags, cookers, stainless steel products and so on.

5. Quotation:

Item	Specification	Unit Price (USD)
Desktop Fiber Laser Marking Machine, Model MT-DP20(Whole Machine Warranty 1 year)	Marking Area110*110MM Or 175*175MM(Please advise us clearly when you place order)  High Quality Fiber Laser Module 20W (Warranty 1 year) High Speed and Precision Galvo Scanner Marking head  JCZ Ezcad Laser Marking Software Laptop Singapore Imported F-thete Lens	EXW 5000USD



6. Optional Parts:



80mm diameter rotary device is optional. The rotary device cost is 250usd/pcs. For Details, please click the links as below:



80MM Diameter Rotary Device

80MM Diameter Rotary Device



Price Terms︰ DHL Door To Door

Payment Terms︰ TT, Western Union, Moneygram

Packing︰ Standard export wooden case

Lead Time︰ 7 days afterpayment received
