1. 3000W cooling capacity; optional environmental refrigerant;
2. +/-0.3C precisely temperature control; +/-0.1C is optional;
3. The intelligent temperature controller has 2 control modes, applicable to different applied occasions; with various setting and display functions;
4. Multiple alarm functions: compressor time-delay protection, compressor overcurrent protection, water flow alarm and over high / low temperature alarm;
5. Multiple power specifications; CE approval;
6. Long working life and simple operation;
7. Optional heater and water filter.
8.One-stop automatic intelligent temperature control: in different environment, user does not need to change setting due to it will automatically switch
to appropriate operating temperature.
9.CW-6000AH: applied to cool three 100W CO2 laser tubes or four 80W CO2 laser tubes;
2. Specification of Industry Water Chiller CW-6000AH:
Model
CW-6000AH
CW-6000BH
CW-6000BI
Voltage
AC 1P 220V
AC 1P 220V
AC 1P 220V
Frequency
50Hz
60Hz
60Hz
Current
1-4.5A
1-4.5A
1.5-5.5A
Compressor power
0.965KW
0.895KW
0.895KW
1.28HP
1.22HP
1.22HP
Refrigerating capacity
10286Btu/h
9502Btu/h
9502Btu/h
3.015KW
2.785KW
2.785KW
2592Kcal/h
2395Kcal/h
2395Kcal/h
Refrigerant
R-22 / R-410a
Refrigerant charge
800g
750g
750g
Precision
+/-0.3 temperature
Reducer
Capillary
Protection
Overcurrent protection for compressor, flow alarm, over temperature alarm
