1. 1400W cooling capacity; optional environmental refrigerant;
2. Compact size, long working life and simple operation;
3. ±0.3C precisely temperature control; ±0.1C is optional;
4. The intelligent temperature controller has 2 control modes, applicable to different applied occasions; with various setting and display functions;
5. Multiple alarm functions: compressor time-delay protection, compressor overcurrent protection, water flow alarm and over high / low temperature alarm;
6. Multiple power specifications; CE approval;
7. Optional heater and water filter.
8.One-stop automatic intelligent temperature control: in different environment, user does not need to change setting due to it will automatically
switch to appropriate operating temperature.
9.CW-5200AG: applied to cool a single 150W CO2 laser tube or dual 100W CO2 laser tubes;
2. Specification of chiller system:
Model
CW-5200AG
CW-5200BG
CW-5200DG
Voltage
AC 1P 220V
AC 1P 220V
AC 1P 110V
Frequency
50Hz
60Hz
60Hz
Current
2.4~3.1A
2.6~3.3A
4.5~6.5A
Compressor power
0.52KW
0.5KW
0.68KW
0.71HP
0.68HP
0.93HP
Refrigerating capacity
5084Btu/h
4982Btu/h
5186Btu/h
1.49KW
1.46KW
1.56KW
1281Kcal/h
1256Kcal/h
1307Kcal/h
Refrigerant
R-22 / R-134a / R-410a
Refrigerant charge
360g
380g
350g
Precision
±0.3 temperature
Reducer
Capillary
Protection
Overcurrent protection for compressor, flow alarm, over temperature alarm
Pump power
0.03KW
Tank capacity
6L
Inlet and outlet
External Φ10mm brass connector
Max. lift
10 M
Max. flow
10 L/min
N.W
30 Kgs
G.W
35 Kgs
Dimension
55 X 28 X 43 cm (L x W x H)
Package dimension
72 X 44 X 62 cm (L x W x H)
This model Industrial Water Chiller is also suitable for rubber industry, plastic industry, chemical industry, injection molding machine, electroplate, refreshing and so on.
